Frame Family
Haibike, SDURO HardSeven, Aluminium 6061, Thru-axle M12 (1.75) x 148mm, Disc brake Post Mount
Fork
RockShox, 35 Gold RL, Air, Travel= 120 mm, 15 x 110mm thru-axle Boost
Rear Derailleur
Sram, SX Eagle
Shift Lever
Sram, SX Eagle, Trigger switch, 12 speed
Sprocket
Sram, Eagle PG1210, 11 - 50 teeth
Bottom Bracket
integrated in the motor
Crank Arm
Haibike Components, The Crank ++, Aluminium
Chain
Sram, SX Eagle
Chain Guide
Haibike aluminium/Nylon directmount
Chainring
Sram, 38 teeth
Brake Lever
Shimano, MT401, Aluminium
Brake Disc (Front)
Shimano, RT30-L
Brake (Front)
Shimano, MT420, 203 mm, 4-piston disc brake
Brake Disc (Rear)
Shimano, RT30-M
Brake (Rear)
Shimano, MT420, 180 mm, 4-piston disc brake
Tube
Presta valve
Tyre
Schwalbe, Nobby Nic Evo SnakeSkin, 70-584, 27.5" x 2.80"
Rim (Rear, If Different)
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Rim
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Front Wheel Hub
Shimano, MT400-B, Centerlock
Rear Wheel Hub
Shimano, Centerlock
Spokes
Sapim, Leader, black
Handlebar
Haibike Components, TheBar ++, 740 mm
Grips
Haibike, MTB grips
Stem
Haibike Components, TheStem 2, A-head, Bar bore: 31.8 mm
Headset
Feimin, A-Head Tapered, Aluminium, cartridge bearing
Saddle
Haibike Components, TheSaddle
Seat Post
Haibike Components, TheSeatpost ++, 31.6 mm, Aluminium
Pedals
Freeridepedal, Aluminium, mit Reflektor
Clamping Ring
Quick release, 34.9 mm
Engine
Bosch, Performance CX, 250 W, 75 Nm, 25 km/h
Weight (Kg)
23.1 kg
Permitted Total Weight
120.0 kg
Battery
Bosch, PowerTube, 500 Wh
