Frame Family
Haibike, SDURO Trekking , Aluminium 6061, Thru-axle M12 (1.75) x 148mm, Disc brake Post Mount
Fork
SR Suntour, Mobie E45 LOR, Lockout, Air, Travel= 80 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 100mm thru-axle
Rear Derailleur
Shimano, M8100
Shift Lever
Shimano, Deore SLX M7100, 12 speed
Sprocket
Shimano, SLX M7100, 10 - 51 teeth
Bottom Bracket
integrated in the motor
Crank Arm
Haibike Components, The Crank ++, Aluminium
Chain
KMC, e11S
Chainring
Haibike Components, Aluminium, 42 teeth
Brake Lever
Magura, MT4
Brake Disc (Front)
Magura, MDR-C
Brake (Front)
Magura, MT4, 180 mm, 2-piston disc brake
Brake Disc (Rear)
Magura, MDR-C
Brake (Rear)
Magura, MT4, 180 mm, 2-piston disc brake
Tube
Presta valve
Tyre
Schwalbe, Super Moto X , 62-584, 27.5" x 2.40"
Rim
Rodi, Tryp 30, with eyelets, hollow rim, Aluminium
Front Wheel Hub
Haibike Components, TheHub ++, 6-bolt standard
Rear Wheel Hub
Haibike Components, 6-bolt standard
Spokes
Sapim, Leader, black
Handlebar
Haibike Components, TheBar ++, 740 mm
Grips
XLC, Comfort bo3
Stem
Haibike Components, TheStem ++, A-head, Bar bore: 31.8 mm, 12°
Headset
Feimin, A-Head Tapered, Aluminium, cartridge bearing
Saddle
Haibike Components, TheSaddle
Seat Post
Haibike Components, The Seatpost +, Patent, 31.6 mm, Aluminium
Pedals
VP, E461, Aluminium, mit Reflektor
Headlight
Haibike, Skybeamer 300, 100 lm
Rear Light
AXA, Blueline
Carrier
system carrier, 25.0 kg
Fenders
SKS, Chromoplastics
Stand
Ursus, Mooi, Rear stand
Clamping Ring
Quick release, 34.9 mm
Engine
Bosch, Performance CX, 250 W, 75 Nm, 25 km/h
Weight (Kg)
25.4 kg
Permitted Total Weight
130.0 kg
Battery
Bosch, PowerTube, 500 Wh
