Frame
Orbea Diem Hydro High Polished 2024, Flex Tech, 135x9 / 142x12, Headset Routing, Custom Kickstand, Orbea Urban Cockpit and equipment compatible
Fork
Orbea Diem carbon fork, full carbon, 1" 1/8 - 1" 1/5 , thru axle 12x1, post mount disc mount, Thrue Axle12x100mm, Long mudguards compatible.
Headset
FSA 1-1/2" Integrated Aluminium Cup
Battery
Orbea Internal 630Wh (Optional 250 Wh Range Extender)
RANGE EXTENDER
N/A Orbea Custom Range Extender 252Wh £ +439
Motor
Shimano EP600
CHARGER
Orbea 2.Generation eBike Smart charger 42V/2-4A
Remote
EN600-L
Chainring
Gates CDX 42t w/chainguard
Crank
Shimano Steps EM600
Shifters
Microshift TN71 for Nexus Inter 5
Cassette
Gates CDX 34t for Shimano Inter 5e
Rear derailleur
Shimano Nexus Inter-5
Chain
Gates CDX Belt
Handlebar
Orbea Urban, Integrated Light, Rise 54, Width 700 Orbea Urban, Integrated Light, Rise 0, Width 720 £ +0
Brakes
Shimano MT201 Hydraulic Disc
Brakes Configuration
Left Road £ +0
Wheels
Alloy, Tubeless, 25c, 32H
Tyres
Vittoria e-Randonneur 50-622, Reflective band
Pedals
VP-537 Black
Front carrier
N/A Orbea Front Carrier RF-01 Alloy, Max. 10Kg, with Basket £ +79
Rear carrier
Orbea RR-01 Alloy, w/Mik & Mik Side and Ortlieb QL3.1 system. Max. 20Kg Orbea RR-02 Alloy, w/MIK HD & Ortlieb QL3.1 System. Max.30Kg £ +29
Mudguard
Curana Apollo Orbit 60mm
Front Position Light
Orbea integrated, USB-C charging point
Front light
Supernova Starstream Pure, Low Beam Supernova Starstream Front Light with Low/High Beam w/remote £ +65
Rear light
Orbea Fender integrated, with alert light
Chainguard
Gates CDS
Quick stand
Orbea Diem Integrated
Bell
Knog OI Classic
Seatpost
Alloy 31.6x300mm Offset 0 OC Mountain Control MC21, 31.6mm, Dropper, Travel 100mm £ +99 OC Mountain Control MC21, 31.6mm, Dropper, Travel 125mm £ +99
Saddle
Selle Royal Vivo Ergo
