Frameset
Frame
Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5 mm QR
Fork
Dual Sport carbon, internal brake routing, mudguard mounts, rack mounts, ThruSkew 5 mm QR
Wheels
Hub front
Dynamo, 6V 3.0 W, 100x5 mm QR
Skewer front
139x5 mm bolt-on
Hub rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Skewer rear
152x5 mm QR
Rim
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Tyre
Bontrager GR0 Comp, wire bead, reflective strip, 60 tpi, 650x50 mm
Max tyre size
27.5x2.00"
Drivetrain
Shifter
Shimano CUES U6000 w/optical gear display, 10-speed
Rear derailleur
Shimano CUES U6000 GS
Crank
Prowheel alloy, 40T narrow-wide ring, 170 mm length
Cassette
Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain
Shimano LG500
Pedal
Wellgo nylon body, alloy cage
Max. chainring size
1x: 42T, 2x/3x: 48T
Components
Saddle
Bontrager H1
Seatpost
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
*Handlebar
Size: S
Bontrager Comp Lowriser, alloy, 31.8 mm, 15 mm rise, 600 mm width
Size: M, L
Bontrager Comp Lowriser, alloy, 31.8 mm, 15 mm rise, 660 mm width
Grips
Bontrager XR Endurance Elite
*Stem
Size: S
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Size: M
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size: L
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Brake
Shimano hydraulic disc, MT201 lever, UR300 calliper
Brake rotor
Shimano RT26, 6-bolt,160 mm
Rotor size
Max brake rotor sizes: 160mm front & rear
Accessories
*Light
Size: S, M, L
Herrmans H-Trace ECO dynamo LED
Size: S, M, L
Herrmans MR4, 100-lumen LED
Kickstand
Alloy, rear-mount kickstand
*Mudguard
Size: S, M, L
SKS wide
Size: S, M, L
SKS plastic, front
Weight
Weight limit
