Frame
100 Series Alpha Aluminium, mudguard mounts, DuoTrap S-compatible, rim brake, 130x5 mm QR
Fork
Domane carbon, straight alloy steerer, mudguard mounts, 5x100 mm QR
Front hub
Formula TK-31 alloy, 5x100 mm QR
Rear hub
Formula TK-32 alloy, Shimano 8/9/10 freehub, 5x130 mm QR
Rim
Bontrager Tubeless Ready, 24-hole, 17 mm width, Presta valve
Spokes
14 g stainless steel
Tyre
Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x28 c
Shifter
Shimano Claris R2000, 8-speed
Front derailleur
Shimano Claris R2000, 31.8 mm clamp
Rear derailleur
Shimano Claris R2000, long cage, 34T max cog
Crank
Size: 47, Shimano RS200, 50/34 (compact), 165 mm length
Size: 50/52/54, Shimano RS200, 50/34 (compact), 170 mm length
Size: 56/58/60/62, Shimano RS200, 50/34 (compact), 175 mm length
Bottom bracket
Shimano UN30, 68 mm, threaded cartridge, 110 mm spindle
Cassette
Shimano HG31, 11-32, 8-speed
Chain
Shimano Sora HG71, 8-speed
Pedal
Wellgo nylon body, alloy cage
Saddle
Size: 47/50/52, Bontrager P3 Verse Comp, steel rails, 155 mm width,
Size: 54/56/58/60/62, Bontrager P3 Verse Comp, steel rails, 145 mm width
Seatpost
Size: 47, Bontrager alloy, 27.2 mm, 12 mm offset, 250 mm length
Size: 50/52/54/56/58/60/62, Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
Handlebar
Size: 47, Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 38 cm width
Size: 50/52, Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 40 cm width
Size: 54/56, Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width
Size: 58/60/62, Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width
Handlebar tape
Bontrager Gel Cork tape
Stem
Size: 47, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Size: 50, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size: 52/54, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Size: 56/58, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Size: 60/62, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
Head set
FSA Integrated, sealed cartridge bearing, 1-1/8"
Brake
Alloy dual-pivot
Weight
56 - 9.57 kg / 21.09 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
