Frame
800 Series OCLV Carbon, TQ drive system, tapered head tube, rear IsoSpeed, internal routing, flat mount disc, mudguard mounts, 142x12 mm thru axle
Fork
Domane+ carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat mount disc, 12x100 mm thru axle
Frame fit
Endurance
Wheel front
Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 100 x 12 mm thru axle
Wheel rear
Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 142 x 12 mm thru axle
Skewer front
Bontrager Switch thru-axle, removable lever
Skewer rear
Bontrager Switch thru-axle, removable lever
Tyre
Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32 mm
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Rim strip
Bontrager TLR
Max tyre size
40 mm without mudguards, 35 mm with mudguards
*Battery
Size: 50, 52, 54, 56, 58, 60, 62
TQ 360Wh
Size: 50, 52, 54, 56, 58, 60, 62
Shimano BT-DN300
*Charger
Size: 50, 52, 54, 56, 58, 60, 62
TQ 4A charger
Size: 50, 52, 54, 56, 58, 60, 62
Charging cable included
Computer
TQ LED display with Bluetooth & ANT+ connectivity
Motor
TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power
Shifter
Shimano Dura-Ace R9270 Di2, 12 speed
Front derailleur
Shimano Dura-Ace R9250 Di2, braze-on, down swing
Rear derailleur
Shimano Dura-Ace R9250 Di2, 34T max cog
*Crank
Size: 50, 52
Praxis Carbon, 170 mm length
Size: 54, 56
Praxis Carbon, 172.5 mm length
Size: 58, 60, 62
Praxis Carbon, 175 mm length
Chainring
Praxis, 50/34T, 12-speed
Cassette
Shimano Dura-Ace R9200, 11-34, 12-speed
Chain
Shimano Dura-Ace/XTR M9100, 12-speed
Max. chainring size
1x: 46T, 2x: 52/36
*Saddle
Size: 50, 52
Verse Short Pro, carbon rails, 155 mm width
Size: 54, 56, 58, 60, 62
Verse Short Pro, carbon rails, 145 mm width
*Seatpost
Size: 50, 52, 54, 56
KVF aero carbon seat post, 20 mm offset, 280 mm length
Size: 58, 60, 62
KVF aero carbon seat post, 20 mm offset, 320 mm length
*Handlebar
Size: 50, 52
Bontrager Pro IsoCore VR-SF, 40cm
Size: 54, 56
Bontrager Pro IsoCore VR-SF, 42cm
Size: 58, 60, 62
Bontrager Pro IsoCore VR-SF, 44cm
Handlebar tape
Bontrager Supertack Perf tape
*Stem
Size: 50
Trek RCS Pro, -7-degree, 80 mm length
Size: 52, 54
Trek RCS Pro, -7-degree, 90 mm length
Size: 56, 58
Trek RCS Pro, -7-degree, 100 mm length
Size: 60, 62
Trek RCS Pro, -7-degree, 110 mm length
Brake
Shimano Dura-Ace BR-9270 hydraulic disc, flat mount caliper, resin pad w/fin.
*Brake rotor
Size: 50, 52, 54, 56, 58, 60, 62
Shimano CL900, CentreLock, 160 mm
Size: 50, 52, 54, 56, 58, 60, 62
Shimano MT900, CentreLock, 160 mm
Rotor size
Max brake rotor sizes: 180 mm front, 160 mm rear
Weight
56 - 11.75 kg/25.91 lb (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
